防爆L型双头套筒扳手
图示-(防爆L型双头套筒扳手)图片
用途：适用于长螺栓螺母紧固和深孔螺栓螺母紧固
材质：铍铜合金，铝铜合金
|
Numvber 序号 |
S mm |
L mm |
H mm |
Be-Cu g |
A1-CU g |
|
1143-6 |
6 |
102 |
18 |
90 |
|
|
1143-7 |
7 |
106 |
18 |
90 |
|
|
1143-8 |
8 |
114 |
22 |
85 |
|
|
1143-9 |
9 |
122 |
25 |
95 |
|
|
1143-10 |
10 |
129 |
25 |
130 |
|
|
1143-11 |
11 |
136 |
25 |
130 |
|
|
1143-12 |
12 |
144 |
28 |
165 |
|
|
1143-13 |
13 |
152 |
30 |
195 |
|
|
1143-14 |
14 |
160 |
32 |
215 |
|
|
1143-15 |
15 |
169 |
35 |
215 |
|
|
1143-16 |
16 |
178 |
35 |
285 |
|
|
1143-17 |
17 |
187 |
40 |
350 |
|
|
1143-18 |
18 |
195 |
40 |
330 |
|
|
1143-19 |
19 |
204 |
45 |
485 |
|
|
1143-21 |
21 |
221 |
50 |
630 |
|
|
1143-22 |
22 |
230 |
50 |
605 |
|
|
1143-24 |
24 |
250 |
55 |
915 |
|
|
1143-27 |
27 |
280 |
65 |
1065 |
|
|
1143-30 |
30 |
310 |
70 |
1460 |
|
|
1143-32 |
32 |
330 |
75 |
1625 |
|
|
1143-34 |
34 |
350 |
75 |
1760 |
|
|
1143-36 |
36 |
340 |
80 |
1965 |
|
